THINK TECH Pneumatic Actuator Operated 2-Piece Ball Valve (Flanged End)

General Description

The pneumatic actuator operated 2-piece flanged ball valve is designed for on/off and flow control applications in industrial pipelines. It combines a quarter-turn rack & pinion pneumatic actuator with a 2-piece flanged ball valve, offering reliable automation and tight shutoff. Available in SS304, SS316, WCB, CI, and CS body materials, these valves are suitable for a wide range of media and operating conditions.

Technical Specifications

• Valve Type: 2-Piece Ball Valve Flanged End

• Operation: Pneumatic Actuator Operated (Single Acting / Double Acting)

• Body Material Options:

  • Stainless Steel 304 (SS304)

  • Stainless Steel 316 (SS316)

  • Cast Steel (CS)

  • Cast Iron (CI)

  • WCB (Carbon Steel, ASTM A216 WCB)

• Ball & Stem: SS304 / SS316

• Seat Material: PTFE / RPTFE / Graphite (depending on temperature & media)

• End Connection: Flanged End ANSI, DIN, JIS Standards

• Size Range: 1/2" to 12" (DN15 DN300)

• Pressure Rating (Class): ANSI Class 150 / 300 / 600

• Actuator Type: Rack & Pinion Pneumatic Actuator

• Actuator Operation: Single Acting (Spring Return) / Double Acting

• Air Supply Pressure: 2.5 8 bar

• Temperature Range: -20C to +200C (depending on seat material)

• Design Standard: API 6D / ISO 5211 / ASME B16.34

• Leakage Class: Bubble-tight shutoff

• Accessories (Optional):

  • Solenoid Valve (NAMUR)

  • Limit Switch Box

  • Positioner (Electro-Pneumatic)

  • Air Filter Regulator

  • Manual Override

Features

• Compact design with reliable rack & pinion actuator

• High sealing performance with PTFE / RPTFE seats

• Available in multiple body materials for different industries

• ISO 5211 mounting pad for direct actuator installation

• Quarter-turn operation with high torque output

• Flanged end design ensures strong pipeline connection

• Options for fire-safe, anti-static, and blowout-proof stem

• Custom coating and special trims available

Applications

• Oil & Gas Pipelines

• Chemical & Petrochemical Plants

• Water Treatment & Effluent Systems

• Power Generation Plants

• Food & Beverage Industry

• Pharmaceutical Industry

• HVAC & Building Automation

• General Industrial Flow Control
