About HFY MODEL PNEUMATIC CYLINDER

THINK TECH HFY Model Pneumatic Cylinder

• Model No.: HFY

• Type: Pneumatic Cylinder (Compact / Heavy-Duty Type)

• Operation: Double Acting

• Magnetic Option: Available with or without magnetic piston (for sensor mounting)

• Bore Sizes: 20, 25, 32, 40, 50, 63, 80, 100 mm (others on request)

• Stroke Range: 10 mm 200 mm (customizable)

• Medium Used: Filtered Compressed Air (40 m filtration recommended)

• Working Pressure Range: 0.1 1.0 MPa (1 10 bar)

• Proof Pressure: 1.35 MPa

• Temperature Range: -5C +70C (no freezing)

• Cushioning: Rubber bumper at both ends (adjustable air cushioning optional)

• Mounting Style: Front flange, rear flange, foot mount, clevis, trunnion, or customized

• Body Material: Hard anodized aluminum alloy / Stainless Steel (optional)

• Piston Rod: High-strength carbon steel with hard chrome plating

• Seals: NBR as standard (Viton available for high temperature/chemical resistance)

• Features:

  • Compact heavy-duty design suitable for limited space

  • Long service life with high reliability

  • Magnetic sensing option for automation control

  • Smooth linear motion with high load capacity

• Applications:

  • General industrial automation

  • Packaging machinery

  • Automotive assembly

  • Clamping, lifting, pressing applications

  • Robotics and pick-and-place units
