SS304 2-2 WAY SOLINOID VALVE NO AND NC

Price 775.0 INR/ Piece

Get a Price/Quote

MOQ : 15 Pieces

SS304 2-2 WAY SOLINOID VALVE NO AND NC Specification

Material
Stainless Steel

Usage
Industrial

Size
Standard

Power
Manual

Pressure
High Pressure

Media
Water

Color
Silver Black

SS304 2-2 WAY SOLINOID VALVE NO AND NC Trade Information

Minimum Order Quantity
15 Pieces

Supply Ability
50 Pieces Per Month

About SS304 2-2 WAY SOLINOID VALVE NO AND NC

THINK TECH 2S Model SS304 2/2 Way Solenoid Valve

Model: 2S Series
Type: 2/2 Way Solenoid Valve (Normally Open & Normally Closed)
Body Material: Stainless Steel 304 (SS304)
Port Size: 1/4 to 2 (BSP / NPT Threaded)
Operation Type:
- Normally Closed (NC): Closes when de-energized, opens when energized
- Normally Open (NO): Opens when de-energized, closes when energized
Medium: Water, Air, Gas, Oil, Steam, Non-corrosive Fluids
Working Pressure: 0 to 10 bar (standard)
Temperature Range: -10C to +180C (based on seal material)
Seal Material: NBR / Viton / EPDM / PTFE (custom available)
Coil Voltage: 12V DC, 24V DC, 24V AC, 110V AC, 220V AC, 230V AC
Coil Protection: IP65 (Dust & Water Resistant), Class F Insulation
Duty Cycle: 100% ED Continuous Working
Operation Method: Direct Acting (small size) / Pilot Operated (large size)
Flow Direction: One Way (indicated by arrow on valve body)
End Connection: BSP / NPT Female Thread (Flange on request)
Certification: ISO / CE / RoHS Compliance

Keywords

2S solenoid valve, SS304 solenoid valve, stainless steel solenoid valve, 2/2 way solenoid valve, normally closed solenoid valve, normally open solenoid valve, water solenoid valve, air solenoid valve, oil solenoid valve, gas solenoid valve, steam solenoid valve, pilot operated solenoid valve, direct acting solenoid valve, 2S series valve, Think Tech solenoid valve.

Superior Durability in Demanding Environments

Manufactured from premium SS304 stainless steel, this solenoid valve is highly resistant to corrosion and wear, making it perfect for challenging industrial conditions. Its robust construction guarantees longevity and consistent performance, even when exposed to high water pressures.

Flexible Configurations for Optimal Control

With both Normally Open and Normally Closed options available, users can tailor flow control strategies to specific process requirements. This flexibility enhances efficiency and safety in industrial water management systems.

FAQs of SS304 2-2 WAY SOLINOID VALVE NO AND NC:

Q: How does the SS304 2-2 Way Solenoid Valve operate in high-pressure water systems?

A: This valve is designed to manage and control the flow of water in high-pressure environments. Its stainless steel construction provides durability, while solenoid technology enables quick switching between open and closed states, maintaining consistent water management.

Q: What are the benefits of choosing a solenoid valve with both NO and NC configurations?

A: Having both Normally Open and Normally Closed options allows greater flexibility in system design, enabling users to select the appropriate configuration for safety, maintenance, or specific operational needs in industrial applications.

Q: When should a manual powered solenoid valve be used over automated versions?

A: Manual power solenoid valves are ideal for applications where electrical automation isnt feasible or where hands-on control is preferred for safety or maintenance reasons, particularly in environments with variable operational needs.

Q: Where is the best place to install this valve in an industrial system?

A: This valve should be installed at critical control points within water distribution or process lines, ensuring easy access for manual operation and maintenance, while handling high-pressure conditions commonly found in industrial settings.

Q: What is the process for maintaining the SS304 solenoid valve?

A: Regular inspection for wear, cleaning of the internal components, and checking for proper sealing ensures optimal performance. Due to its stainless steel build, the valve is resistant to corrosion, reducing maintenance frequency compared to other materials.

Q: How does the choice of stainless steel enhance the valves performance and longevity?

A: Stainless steel, specifically SS304, offers outstanding resistance to corrosion and physical stress, which protects the valve during continuous operation in harsh conditions and extends its service life, ensuring dependable operation for industrial users.
