About FORGED STEEL GLOBE VALVE

THINK TECH Forged Steel Globe Valve Flanged End Specification

General Description

The Forged Steel Globe Valve Flanged End is designed for throttling and shut-off service in pipelines handling steam, oil, gas, and corrosive fluids. Built from forged steel for superior strength and durability, it provides leak-proof tight shut-off and excellent flow control under high pressure and temperature conditions.

Technical Specifications

• Valve Type: Forged Steel Globe Valve Flanged End

• Size Range: to 2 (DN15 DN50)

• Body & Bonnet Material:

  • Forged Carbon Steel (A105)

  • Alloy Steel (F11 / F22)

  • Stainless Steel (SS304 / SS316)

• Trim (Disc & Seat): Stainless Steel / Hard-faced (Stellite on request)

• End Connections: Flanged Ends (ANSI / DIN / JIS standards)

• Pressure Rating: Class 150 / 300 / 600 / 800 / 1500

• Temperature Range:

  • -29C to +425C (Carbon Steel)

  • Up to +600C (Alloy Steel / Stainless Steel)

• Design Standard: API 602 / ASME B16.34 / BS 5352

• Testing Standard: API 598 / EN 12266

• Operation: Manual Handwheel (Optional Gear Operation for higher sizes)

Features

• Rugged forged steel construction for high strength & reliability

• Rising stem with precision throttling capability

• Flanged ends for easy pipeline installation & removal

• Tight sealing with stainless steel / hard-faced seat

• Backseat arrangement for stem packing replacement under pressure

• Compact design suitable for high pressure service

• Long service life with reduced maintenance

Applications

• Steam service lines

• Oil & Gas pipelines

• Power generation plants

• Chemical & Petrochemical plants

• Process industries

• High-pressure & high-temperature service lines
