Dnc Model Magnetic And Non Magnetic Iso Pneumatic Cylinder

Product Description

General Features:

• Standard Compliance: Adhere to ISO 15552, ensuring standardized dimensions and mounting options for easy integration and replacement.
• Operating Medium: Typically operate with filtered compressed air (e.g., to ISO 8573-1:2010 [7:4:4]). Lubricated operation is possible, but if introduced, it must be maintained.
• Acting Type: Primarily double-acting, meaning air pressure extends and retracts the piston rod, providing force in both directions. Single-acting versions (spring extend or spring return) may also be available for specific applications.
• Construction: Feature a robust design, often with an aluminum profile barrel (square or round) and a high-strength piston rod (e.g., 45# carbon steel or stainless steel for corrosion resistance).
• Cushioning: Equipped with adjustable pneumatic cushioning at both ends to absorb kinetic energy, reduce noise, and extend cylinder lifespan by preventing hard stops. Some models may also have elastic cushioning rings/pads.
• Mounting: Offer a wide range of mounting accessories as per ISO 15552, including foot, front flange, rear flange, trunnion, and clevis mounts, allowing for versatile installation in various orientations.
• Operating Temperature: Generally operate within a temperature range of approximately -5C to 70C, with high-temperature versions (e.g., up to 150C with Viton seals) available for specialized environments.
• Working Pressure: Typically rated for working pressures from 0.1 MPa (1 bar) to 1.0 MPa (10 bar), with a guaranteed pressure of around 1.35 MPa.
• Speed Range: Capable of operating at speeds typically between 50 and 800 mm/s.
