BRONZE GATE VALVE BODY CS CI WCB SS304 SS316 CLASS 150-300- 600

Price 1000 INR/ Piece

Get a Price/Quote

MOQ : 15 Pieces

BRONZE GATE VALVE BODY CS CI WCB SS304 SS316 CLASS 150-300- 600 Specification

Material
Brass

Features
Pneumatic Circuits, Fluid Control

Usage
Industrial

Power
Manual

Pressure
Medium Pressure

Media
Water

Port Size
1/2" 3/4" 1" 1.1/4" 1.1/2" 2" 2.1/2" 3" 4" 5" 6"

BRONZE GATE VALVE BODY CS CI WCB SS304 SS316 CLASS 150-300- 600 Trade Information

Minimum Order Quantity
15 Pieces

Supply Ability
50 Pieces Per Month

About BRONZE GATE VALVE BODY CS CI WCB SS304 SS316 CLASS 150-300- 600

THINK TECH Gate Valve Bronze / CS / CI / WCB / SS304 / SS316 Flanged End

General Description

The Flanged End Gate Valve is a robust, full-bore shut-off valve suitable for a wide range of industrial applications. Available in Bronze, Cast Steel (CS/WCB), Cast Iron (CI), and Stainless Steel (SS304/SS316), these valves provide excellent sealing, durability, and corrosion resistance. Designed for Class 150 / 300 / 600 pressure ratings, they are ideal for water, oil, gas, steam, and chemical service.

Technical Specifications

Valve Type: Gate Valve Flanged End
Size Range: 2 to 24 (DN50 DN600)
Body Material Options:
- Bronze
- Cast Iron (CI)
- Cast Steel (WCB)
- Carbon Steel (CS)
- Stainless Steel SS304 / SS316
Bonnet: Same as body material
Wedge / Gate: Stainless Steel / Bronze / Hard-faced (Stellite on request)
Stem: Stainless Steel Rising / Non-rising type
Seat: Renewable / Integral seat in SS / Bronze / Hard-faced
End Connection: Flanged Ends ANSI B16.5 (Class 150 / 300 / 600), DIN / JIS standards also available
Pressure Rating: Class 150, 300, 600
Temperature Range: -29C to +425C (Carbon Steel / Bronze) | Up to +600C (Stainless Steel / Alloy Steel)
Design Standard: API 600 / API 602 / BS 1414 / ASME B16.34
Testing Standard: API 598 / EN 12266
Operation: Handwheel (manual) | Gear Operated for larger sizes

Features

Full-bore design with minimal pressure drop
Rugged body construction with multiple material options
Bubble-tight shut-off with renewable / hard-faced seat
Rising stem design for clear valve status indication
Flanged ends for easy pipeline installation & removal
Long service life with low maintenance requirements

Applications

Water Supply & Distribution
Oil & Gas Pipelines
Chemical & Petrochemical Plants
Power Generation Units
Food & Beverage Industry (with SS316 option)
Marine & Offshore Industry
General Industrial Piping

Keywords

Bronze Gate Valve Flanged End
Cast Steel Gate Valve WCB Flanged
Cast Iron Gate Valve CI Flanged
Stainless Steel SS304 Flanged Gate Valve
Stainless Steel SS316 Flanged Gate Valve
Carbon Steel Gate Valve Flanged End
Class 150 Gate Valve Flanged End
Class 300 Gate Valve Flanged End
Class 600 Gate Valve Flanged End
API 600 Gate Valve Flanged End
Industrial Flanged Gate Valve Manufacturer / Supplier / Exporter

Versatile Material Options

The BRONZE GATE VALVE BODY is available in multiple high-performance materials, including carbon steel, cast iron, WCB, SS304, SS316, and brass. These choices ensure compatibility with various industrial fluids, providing excellent longevity and resistance to corrosion in demanding environments.

Wide Port Size Range

This valve accommodates a comprehensive selection of port sizes, ranging from 1/2" to 6". This versatility allows seamless integration into industrial systems of different capacities, ensuring optimal flow control regardless of application requirements.

Engineered for Industrial Performance

With a medium-pressure rating (Class 150, 300, and 600) and manual operation, the BRONZE GATE VALVE BODY is rigorously constructed for demanding industrial uses, particularly in fluid control and pneumatic circuits. Its robust build guarantees consistent and reliable performance.

FAQs of BRONZE GATE VALVE BODY CS CI WCB SS304 SS316 CLASS 150-300- 600:

Q: How is the BRONZE GATE VALVE BODY typically installed in industrial systems?

A: Installation is usually performed by threading or bolting the valve into the existing pipeline at the designated port size, ensuring a tight seal according to manufacturer guidelines. Professional installation is recommended for optimal performance and safety.

Q: What fluids are suitable for this gate valve?

A: The valve is specifically designed for water but can also handle other non-corrosive fluids compatible with brass, carbon steel, cast iron, WCB, SS304, or SS316, depending on selected material. Always verify fluid compatibility before application.

Q: When should I choose a Class 150, 300, or 600 pressure rating?

A: The selection depends on your systems operating pressure. For lower pressure applications, Class 150 is suitable, while more demanding environments requiring higher resistance to pressure should use Class 300 or 600. Refer to your system requirements and safety standards.

Q: Where are these gate valves commonly used?

A: These valves are widely employed in industrial environments across water treatment, chemical processing, and pneumatic circuits, anywhere reliable shut-off and fluid control are necessary.

Q: What is the process for fluid control with a manual gate valve?

A: To control fluid, the operator turns the handwheel to lift or lower the gate, thus starting, stopping, or regulating fluid flow precisely. The manual operation ensures straightforward, fail-safe control.

Q: What are the primary benefits of using this valve in an industrial setting?

A: The benefits include robust durability, wide material and size selection, reliable shut-off performance, resistance to corrosion, and simple manual operationmaking it ideal for diverse fluid control challenges.
